A specialist L-series tilt-and-shift lens
Control perspective and depth-of-field in portrait and product photography thanks to carefully calibrated movements, outstanding optical engineering and precision moulded glass for low distortion, even at 1:2 macro ratio.
Fine tune depth-of-field
Change the plane of focus to direct more attention to the subject and adjust depth-of-field as you see it, with no need for computers.
Correct subject distortion
Precise movements allow a ± 10° Tilt and a ±12mm Shift with a rotation of the shift/tilt functions +/-90° in any direction for superb perspective control.
Adjust focus in macro shots
A macro focus capability of 39cm means 1:2 life size images can be delicately focused with added control over perspective and depth-of-field.
Excellent optics and design
Aspherical and UD lens elements minimise chromatic aberration while Air Sphere Coating minimises ghosting and flare.
Pleasing 90mm focal length
A 90mm focal length gives a flattering compression for portraits with the added benefit of perspective control to correct verticals and maximise depth-of-field.
Key Features
± 10° Tilt and ±12mm Shift range
Aspherical and UD lens elements
Air Sphere Coating
Specifications in detail
Optical Features/Specifications
Image Size
-
35mm film equivalent focal length (mm)
-
Angle of view (horzntl, vertl, diagnl)
22º 40', 15º 10', 27º
Lens construction (elements/groups)
11/9
No. of diaphragm blades
9
Minimum aperture
45
Closest focusing distance (m)
0.390
Maximum magnification (x)
0.50
Distance Information
Yes
Image stabilizer
-
AF actuator
-
Accessories
Lens cap
E-77 II
Lens hood
ES-84
Lens case/pouch
LP1219
Rear cap
Lens Dust Cap E
Magnification with Extension Tube EF12 II
0.64-0.15
Magnification with Extension Tube EF25 II
0.82-0.32
Extender Compatiblity
Not Compatible
Other Accessories
-
